Computational Fluid Dynamics (CFD)


Why We Turned to CFD to Validate Heat Pump Performance


Air Source Heat Pumps (ASHPs) are often seen as a go-to solution in the push for low-carbon building upgrades. They’re now being installed almost everywhere, from homes to hospitals to higher education campuses. But while they’re a key tool in the transition to net zero, the reality we’re find is that heat pumps don’t just “work” any-where, no matter the setting.

To perform efficiently, ASHPs rely on sufficient airflow, appropriate placement, and minimal disruption from surrounding structures. In practice, however, these factors are often overlooked, especially in retrofits where space is tight, and system siting is constrained.

This was exactly the challenge we faced on a decarbonisation project for a college building. The site proposed for the new heat pumps was an enclosed courtyard with very limited options for positioning the units. With tight spatial constraints and no obvious "ideal" location, we needed to be sure the system would operate effectively before any installation went ahead.

Computational Fluid Dynamics (CFD)

Using IES Virtual Environment software, we modelled the airflow and thermal behaviour around the proposed ASHP units. The goal was to test whether expelled cold air would recirculate in the courtyard and be drawn back into the units, undermining performance, reducing efficiency, and increasing energy use.

The CFD simulation was set up under worst-case winter conditions: still air, ambient temperatures at -5°C, and full system operation. The analysis revealed some degree of exhaust air recirculation. However, most of the cold air discharged vertically and dispersed efficiently, minimising the risk of system short-circuiting.

In short, CFD gave us the confidence that, even in a challenging and space-constrained setting, the heat pump installation could perform reliably without compromising on environmental or operational goals.

As more buildings look to decarbonise, CFD offers a vital layer of assurance, helping avoid costly mistakes and ensuring that low-carbon systems actually deliver in real-world conditions.

To find out more about CFD, get in touch with the team.
